· Hoher Bildkontrast
· Hohe Helligkeitsgleichmäßigkeit
· Geeignet für 2,4u-Sensor, Auflösung bis zu 10 MP
· Kompakt, leicht und langlebig
| Taurus Series 1 ″ Format FA- Objektiv ( 10 MP) |
|||
| Modell |
UN-TFA1220L -10MP |
||
| Brennweite |
12 mm |
|
|
| Öffnung |
F2.0-F22 |
||
| Bildformat |
1"(16mm) |
||
| Montieren |
C |
||
|
Feldwinkel
|
|
T x H x V (°) |
|
| 1" |
67,6°×56,7°×43,5° |
||
| 1/2'' |
36,17°×30,1°×23,13° |
||
| 1/3" |
27,78°×23,14°×16,97° |
||
| Optische Verzerrung |
<-0,8 % |
||
| MOD |
0,1 m |
||
| Abmessungen |
Φ41*62,6 mm |
||
| Flansch BFL |
1 7 . 5 26mm |
||
| Hintere Brennweite _ _ _ |
10,5 mm |
||
| Betrieb |
Manuelle Iris |
||
| Manueller Fokus |
|||
| Design-Wellenlänge |
420–1000 nm |
||
| Thread filtern |
M37,5×P0,5 |
||
| |
|||
heiße Tags :
Nächster :
UN-TFA1620L-10MP
UN-TFA1620L-10MP
UN-TFA2518L-10MP
UN-TFA3520L-10MP
UN-TFA5020L-10MP
UN-TFA1220X-12MP
| Taurus Series 4/3 ″ Format FA- Objektiv ( 12 MP) |
|||||
| Modell |
UN-TFA1220X-12MP |
||||
| Brennweite |
12 mm |
|
|||
| Öffnung |
F 2,0-F22 |
||||
| Bildformat |
4/3 ″ (23mm) |
||||
| Montieren |
C |
||||
|
Feldwinkel T x H x V (°) |
|
4/3 ″ |
1 ″ |
1/2" |
|
| D |
89,1° |
6 9 . 0 ° |
37,4 ° |
||
| H |
7 5 . 6 ° |
57,36 ° |
30,2 ° |
||
| V |
61 . 2 ° |
44 . 3 ° |
22,7 ° |
||
| Optische Verzerrung |
-2,05 %@ y=11,5mm |
-1,73 %@ y=8,0 mm |
-1,01 %@ y=4,0 mm |
||
| MOD |
0,15 m |
||||
| Abmessungen |
Φ 79,8 * 83,8 mm |
||||
| Hintere Brennweite |
18,8 mm |
||||
| Betrieb |
Manuelle Iris |
||||
| Manueller Fokus |
|||||
| Design-Wellenlänge |
420–1000 nm |
||||
| Thread filtern |
M77,0×P0,75 |
||||
| Gewicht _ |
438g |
||||
| Arbeitstemperatur _ _ |
-20℃ ～+60 ℃ |
||||
| |
|||||
UN-ALS858K
| Zeilenobjektiv der Aries- Serie ( 8 K ) |
||
| Modell |
UN-ALS858K |
|
| Brennweite |
85 mm |
|
| Öffnung |
F 2.8 |
|
| Bildformat |
38 |
|
| Montieren |
M42 |
|
| Feldwinkel |
23,1 ° *16,8 ° *9,1 ° |
|
| Optische Verzerrung |
<-0,15 % |
|
| MOD |
0,6 m |
|
| Abmessungen |
Φ 58,5 * 59,87 mm |
|
| Flansch BFL |
46,5 mm |
|
| Hintere Brennweite _ _ _ |
23,93 mm |
|
| Betrieb |
Manuelle Iris |
|
| Manueller Fokus |
||
| Thread filtern |
M 55 *0. 7 5 |
|
 |
||
Line Scan Lens UN-ALS10024K
For semiconductor and precision electronics manufacturing inspection and alignment, new energy lithium-ion battery defect detection, ultra-thin flat panel display surface defect inspection, and high-speed printing quality inspection.
· Developed for 72mm big frame sensor
· Compatible for 24K line scan camera
· IR correction
· Excellent optical performance, uniform imaging of center and edge
Product information: Custom designs are available upon request.
ITS Lens UN-AT55012S-12MP
For Intelligent Transportation Systems (ITS) Applications: Road Surveillance, ANPR/ALPR, Automatic Incident Detection, Traffic Enforcement Systems, Railway/Tunnel Safety Monitoring, etc.
· Excellent edge sharpness and uniform illumination
· Designed to resist strong light interference, adaptable to complex lighting conditions
· High stability and low distortion ensure measurement accuracy
