UN-LFA1236C-10MP
UN-AT16014S-12MP
Product Features:
· Excellent edge sharpness and uniform illumination
· Designed to resist strong light interference, adaptable to complex lighting conditions
· Ultra-high resolution,accurately capture license plates and facial details
Product information: Custom designs are available upon request.
UN-AT25014C-12MP
Product Features:
· Excellent edge sharpness and uniform illumination
· Designed to resist strong light interference, adaptable to complex lighting conditions
· Ultra-high resolution,accurately capture license plates and facial details
Product information: Custom designs are available upon request.
UN-AT35014S-12MP
Product Features:
· Excellent edge sharpness and uniform illumination
· Designed to resist strong light interference, adaptable to complex lighting conditions
· Ultra-high resolution,accurately capture license plates and facial details
Product information: Custom designs are available upon request.
UN-AT50014S-12MP
Product Features:
· Excellent edge sharpness and uniform illumination
· Designed to resist strong light interference, adaptable to complex lighting conditions
· Ultra-high resolution,accurately capture license plates and facial details
Product information: Custom designs are available upon request.
UN-TFA2518X-12MP
| Taurus Series 4/3 ″ Format FA- Objektiv ( 12 MP) |
|||||
| Modell |
UN-TFA2518X-12MP |
||||
| Brennweite |
25 mm |
|
|||
| Öffnung |
F 2,0-F22 |
||||
| Bildformat |
4/3 ″ (23mm) |
||||
| Montieren |
C |
||||
|
Feldwinkel T x H x V (°) |
|
4/3 ″ |
1 ″ |
1/2" |
|
| D |
49,8 ° |
35,8 ° |
18,3 ° |
||
| H |
40,6 ° |
28,9 ° |
14,6 ° |
||
| V |
31,1 ° |
21,8 ° |
11,1 ° |
||
| Optische Verzerrung |
-0,64 %@ y=11,5mm |
-0,48 %@ y=8,0 mm |
-0,15 %@ y=4,0 mm |
||
| MOD |
0,15 m |
||||
| Abmessungen |
Φ 47,3 * 82,7 mm |
||||
| Hintere Brennweite |
22mm |
||||
| Design-Wellenlänge |
420–1000 nm |
||||
| Betrieb |
Manuelle Iris |
||||
| Manueller Fokus |
|||||
| Thread filtern |
M46,0×P0,75 |
||||
| Gewicht _ |
248 g |
||||
| Arbeitstemperatur _ _ |
-20℃ ~ +60℃ |
||||
| |
|||||
UN-TFA2528C-10MP
| Kompaktes FA- Objektiv der Taurus- Serie ( 10 MP) |
|||||
| Modell |
UN-TFA 25 28C -10MP |
||||
| Brennweite |
25 mm |
|
|||
| Öffnung |
F2.8-16 |
||||
| Bildformat |
2,3 ″ |
||||
| Montieren |
C |
||||
|
Feldwinkel T x H x V (°) |
|
2/3 ″ |
1/2 ″ |
1/3" |
|
| D |
2 4. 78 ° |
18 . 16 ° |
13,67 ° |
||
| H |
19 . 94 ° |
1 4 . 57 ° |
10,90 ° |
||
| V |
1 5,00 ° |
1 1 , 0° |
8,20 ° |
||
| Optische Verzerrung |
-0. 016 % y=5. 0 5 mm |
-0. 019% y=4. 0mm |
-0,08 % y = 3,0 mm |
||
| MOD |
0,15m~ ∞ |
||||
| Abmessungen |
Φ 28 * 28,07 mm |
||||
| 17,526 mm |
|||||
| Hintere Brennweite _ _ _ |
10,31 mm |
||||
| Betrieb |
Manuelle Iris |
||||
| Manueller Fokus |
|||||
| Design-Wellenlänge |
420–1000 nm |
||||
| Thread filtern |
M27xP0,5 |
||||
 |
|||||
Plankonkave kreiszylindrische Linsen
hochreflektierende breitbandige dichroitische Spiegel
nicht polarisierende Würfelstrahlteiler (npbs)
