UN-LFA1236C-10MP
UN-AT16014S-12MP
Product Features:
· Excellent edge sharpness and uniform illumination
· Designed to resist strong light interference, adaptable to complex lighting conditions
· Ultra-high resolution,accurately capture license plates and facial details
Product information: Custom designs are available upon request.
UN-AT25014C-12MP
Product Features:
· Excellent edge sharpness and uniform illumination
· Designed to resist strong light interference, adaptable to complex lighting conditions
· Ultra-high resolution,accurately capture license plates and facial details
Product information: Custom designs are available upon request.
UN-AT35014S-12MP
Product Features:
· Excellent edge sharpness and uniform illumination
· Designed to resist strong light interference, adaptable to complex lighting conditions
· Ultra-high resolution,accurately capture license plates and facial details
Product information: Custom designs are available upon request.
UN-AT50014S-12MP
Product Features:
· Excellent edge sharpness and uniform illumination
· Designed to resist strong light interference, adaptable to complex lighting conditions
· Ultra-high resolution,accurately capture license plates and facial details
Product information: Custom designs are available upon request.
optisches Glas
UN-GSWIR4016L
Produkteigenschaften:
· Entwickelt für das φ28-Bildformat
· Wellenlänge: 900-1700 nm
· Große Blende, bis zu F1.4
· Kompaktes und leichtes Design
mgf2-beschichteter Pentaprisma-Strahlteiler
UN-TFA1220X-12MP
| Taurus Series 4/3 ″ Format FA- Objektiv ( 12 MP) |
|||||
| Modell |
UN-TFA1220X-12MP |
||||
| Brennweite |
12 mm |
|
|||
| Öffnung |
F 2,0-F22 |
||||
| Bildformat |
4/3 ″ (23mm) |
||||
| Montieren |
C |
||||
|
Feldwinkel T x H x V (°) |
|
4/3 ″ |
1 ″ |
1/2" |
|
| D |
89,1° |
6 9 . 0 ° |
37,4 ° |
||
| H |
7 5 . 6 ° |
57,36 ° |
30,2 ° |
||
| V |
61 . 2 ° |
44 . 3 ° |
22,7 ° |
||
| Optische Verzerrung |
-2,05 %@ y=11,5mm |
-1,73 %@ y=8,0 mm |
-1,01 %@ y=4,0 mm |
||
| MOD |
0,15 m |
||||
| Abmessungen |
Φ 79,8 * 83,8 mm |
||||
| Hintere Brennweite |
18,8 mm |
||||
| Betrieb |
Manuelle Iris |
||||
| Manueller Fokus |
|||||
| Design-Wellenlänge |
420–1000 nm |
||||
| Thread filtern |
M77,0×P0,75 |
||||
| Gewicht _ |
438g |
||||
| Arbeitstemperatur _ _ |
-20℃ ～+60 ℃ |
||||
| |
|||||
